12Volt or 12/24 volt auto-work negative or positive ground
PWM or ON/OFF series battery charging options
State of charge (SOC) battery regulation
Battery Ah setting, boost charging, equalising charging, float charging
With external temperature sensor, and temperature compensation.
LCD display: SOC as a fuel gauge, all system parameters in digital value, system status as symbols
Full circuit protection, electronic fuse • Field adjustable parameters by four buttons
Real clock display
Load control option:
ON/OFF MODE, LIGHTING ON + EXACT TIME OFF, EXACT TIME ON/OFF, EXACT TIME ON/OFF
PWM or ON/OFF series battery charging options
State of charge (SOC) battery regulation
Battery Ah setting, boost charging, equalising charging, float charging
With external temperature sensor, and temperature compensation.
LCD display: SOC as a fuel gauge, all system parameters in digital value, system status as symbols
Full circuit protection, electronic fuse • Field adjustable parameters by four buttons
Real clock display
Load control option:
ON/OFF MODE, LIGHTING ON + EXACT TIME OFF, EXACT TIME ON/OFF, EXACT TIME ON/OFF
Rated solar input : 30A
Rated load : 30A
System voltage : 12/24V
Regulation Voltage: 14.4V
Float: 13.4V
Equalization: 14.8V
Load Disconnect: 11.1V
Load Reconnect: 12.6V
Temp.Comp.(mV/℃): -30mV
Self-consumption : ≤30mA
Operation temperature: -35 to +65
Rated load : 30A
System voltage : 12/24V
Regulation Voltage: 14.4V
Float: 13.4V
Equalization: 14.8V
Load Disconnect: 11.1V
Load Reconnect: 12.6V
Temp.Comp.(mV/℃): -30mV
Self-consumption : ≤30mA
Operation temperature: -35 to +65
