תיאור
מתח כניסה: 8.5V~48V
מתח יציאה: 10V~50V
זרם: עד 10A
טמפרטורת עבודה: -40 + 85
נצילות: 96%
מידה: 70mmx36mmx13mm
Input voltage: DC 8.5V-48V
Input current: 10A (MAX) exceeds 8A please enhance heat dissipation
Quiescent current: 10mA (12V liter 20V, the output voltage, the higher
the current will increase too quiet)
Output voltage: 10-50V continuously adjustable
Constant range: 0.2-8A
Temperature: -40 to + 85 degrees (ambient temperature is too high, please enhance heat dissipation)
Operating frequency: 150KHz
Overcurrent protection: Yes.
Input reverse polarity protection: Yes.
Connection method: Connection Output
Single module: 50 g
Input current: 10A (MAX) exceeds 8A please enhance heat dissipation
Quiescent current: 10mA (12V liter 20V, the output voltage, the higher
the current will increase too quiet)
Output voltage: 10-50V continuously adjustable
Constant range: 0.2-8A
Temperature: -40 to + 85 degrees (ambient temperature is too high, please enhance heat dissipation)
Operating frequency: 150KHz
Overcurrent protection: Yes.
Input reverse polarity protection: Yes.
Connection method: Connection Output
Single module: 50 g
